Anemometer

AMF002 Digital Anemometer

Keywords: digital anemometer, AMF002 anemometer, air velocity meter, handheld anemometer, wind speed meter

Handheld digital anemometer with a detachable vane, 0–45 m/s air velocity range and Max/Min/Average reading functions.

The AMF002 is a handheld digital anemometer for air velocity and air temperature measurement. It reads velocity from 0 to 45 m/s with ± 3 % accuracy and can show the same value in m/s, ft/min, knots, km/h or mph, while air temperature is measured from 0 to 45 ℃ in either °C or °F.

The vane head is detachable and connects by cable, which makes it possible to reach into duct openings and grilles that a fixed-head meter cannot. Max, min, average and current velocity readings are all available, the display can be frozen with data hold, and the backlight makes readings visible in dim plant rooms. Power comes from a standard 9 V battery.

AMF002 Digital Anemometer | 45 m/s Air Velocity

Key Features

1.  Air Velocity to 45 m/s — 0–45 m/s with ± 3 % accuracy, covering low draughts through to strong airflow.

2.  Five Velocity Units — m/s, ft/min, knots, km/h and mph with °C / °F selection.

3.  Detachable Vane Head — the vane connects by cable so readings can be taken inside ducts and grilles.

4.  Air Temperature Measurement — 0–45 ℃ with ± 2 ℃ accuracy in °C or °F.

5.  Max / Min / Average Reading — all three statistics plus the current value for characterising fluctuating airflow.

6.  Data Hold — freezes the display to record a value without writing it down mid-measurement.

7.  Backlight Display — keeps the LCD readable in dim plant rooms and at night.

8.  Low Battery Indication — warns before the 9 V battery is too weak for accurate readings.

9.  Manual / Auto Power Off — shuts down after 14 minutes without operation, or manually at any time.

10.  PP Box and Gift Box Packing — supplied in a protective PP box inside a gift box.

Built for Real Use

Close-up of the control and display area.

Detail view of the body, finish and markings.

Close-up of the connections and mounting section.

Technical Specifications

Applications

1.  HVAC commissioning and routine airflow checks.

2.  Industrial ventilation, extraction and drying equipment surveys.

3.  Agriculture and greenhouse airflow verification.

4.  General wind speed measurement outdoors and in workshops.
