AMF085 Digital Lux Meter
Handheld illuminance & temperature meter, 0–200,000 Lux, with auto data storage and USB/LuxLAB software
| Measuring Range | 0 – 200,000 Lux (auto 4-range) |
| Illuminance Accuracy | ±3% rdg (below 10,000 Lux); ±4% rdg (above 10,000 Lux) |
| Temperature Range | 0–40°C, Accuracy ±1.0°C |
| Data Storage | 1,900 groups automatic / 60 groups manual |
| Units | Lux/°C, Lux/°F, FC/°C, FC/°F |
| Power Supply | Two AAA batteries |
The AMF085 is a handheld digital lux meter for measuring illuminance and ambient temperature. It reads current, maximum, minimum, difference, integrating, and average integrating illuminance, and stores up to 1,900 readings automatically for later review through the included LuxLAB software.
Description
AMF085 Digital Lux Meter | Handheld Illuminance & Temperature Meter
Keywords: Digital Lux Meter, Light Meter, Illuminance Meter, Digital Illuminance Meter, Foot Candle Meter
Wide Range. Auto-Logging. Ready in a Glance.
The AMF085 is a handheld digital lux meter designed for researchers, electricians, agronomists, and quality inspectors who need dependable illuminance readings on the spot. Using a rotating silicon photodiode sensor, the AMF085 measures illuminance across the full 0–200,000 lux range together with ambient temperature — no manual range switching, no separate thermometer needed.
Why Choose the AMF085 Digital Lux Meter
- Full-Range Auto Switching — Four internal ranges cover 0 to 200,000 lux automatically, so the display always shows the right resolution without you touching a dial.
- 1,900-Reading Auto Memory — Log up to 1,900 groups of data automatically, or store 60 groups manually, then pull every reading onto a computer through the bundled LuxLAB software.
- Current, Max, Min & Integrating Modes — Beyond a simple snapshot, the AMF085 tracks illuminance difference, integrating illuminance, and average integrating illuminance over time.
- Rotating Sensor Head — The photoelectric element pivots independently of the display, making awkward angles and overhead fixtures easy to reach with one hand.
- USB & Backlit Display — A backlit LCD keeps readings legible in dim rooms, while the USB connection extends battery life to 10 hours of continuous use.
Function Overview
1. Main Measurements
- Current illuminance and temperature
- Illuminance difference
- Maximum illuminance and temperature
- Minimum illuminance and temperature
- Integrating illuminance
- Average integrating illuminance
2. Storage, Query, and Deletion of Illuminance Data
- Illuminance data (1,900 groups at most) can be stored automatically, queried, and deleted.
- Illuminance data (60 groups at most) can be stored manually.
3. Other Functions
- Auto shutdown
- Backlight and data hold
- Optional units for illuminance and temperature
- Auto shutdown setting
- Auto data storage setting
- Deletion of integrating illuminance data
Specification
| Measurable Objects | Illuminance and temperature, illuminance difference, maximum and minimum illuminance and temperature, integrating illuminance, integrating time, and average integrating illuminance |
|---|---|
| Photoelectric Element | Silicon diode |
| Thermal Probe | NTC thermistor |
| Illuminance Measuring Range |
Total measuring range: 0–200,000 Lux, into four ranges ×1: 0–199.9 Lux | ×10: 200–1999.9 Lux | ×100: 2000–19999.9 Lux | ×1000: 20000–200000 Lux |
| Temperature Measuring Range | 0–40°C |
| Illuminance Accuracy | ±3%rdg (below 10,000 Lux); ±4%rdg (above 10,000 Lux) |
| Temperature Accuracy | ±1.0°C |
| Units of Illuminance & Temperature | Four combinations of units are available: Lux/°C, Lux/°F, FC/°C, FC/°F |
| Illumination Data Storage |
Automatic: Up to 1,900 groups of data can be stored. LuxLAB is used to set the storage cycle and whether to start or stop storage. Manual: Up to 60 groups of data can be stored. Whether to store is determined manually. |
| LCD Display Update Frequency | Twice per second |
| Operating Temperature/Humidity | 0–40°C, 10–90%RH |
| Storage Temperature/Humidity | -20–50°C, 10–90%RH |
| Power Supply | Two AAA batteries |
| Battery Life | 10 hours (continuous operation with a USB connection) |
| Auto Shutdown | You can set an auto shutdown timer through LuxLAB. |
Applications
Specific declarations: our company holds no responsibility for outcomes resulting from using the output of this product as direct or indirect evidence. We reserve the right to modify product design and specification without notice.
